Equator

1006685 Banana

PVC Free Polyurethane
Bleach Cleanable
FR Free – Compliant with CAL AB 2998

Flammability Wet Dry Crock Colorfast Phys Prop Abrasion

*

*ACT® Registered Certification Marks

Technical Details

Fabric Specifications
Face 100% PVC Free Polyurethane
Backing 100% Polyester
Weight 18.0 oz. per linear yd
Thickness 0.80 mm
Width 54"
Roll Size 30 yards
Directional No
Railroaded No
Additional Attributes
PVC Free Yes
Bleach Cleanable Yes
Ratio: 75% Water / 25% Bleach Solution
Free of Added Anti-Bacterial Chemicals Yes
Antimicrobial Yes
BPA Free Yes
Formaldehyde Free Yes
Free of Added FR Chemicals / CAL AB2998 Compliant Yes
Free of Conflict Minerals Yes
Free of Heavy Metals Yes
Lead Free Yes
Mildew Resistant Yes
16P Phthalate Free Yes
Sulfide Stain Resistant Yes
TRIS Free Yes
Performance Characteristics
Abrasion Resistance ASTM D4157 1,000,000 double rubs*
Tensile Strength CFFA-17 Warp: 131.0 lbs.
Fill: 83.0 lbs.
Tear Strength CFFA-16 Warp: 10.2 lbs.
Fill: 13.2 lbs.
Colorfastness to Crocking AATCC 8 Dry: 5.0
Wet: 5.0
UV Resistance CFFA-2 1400 hours
Cold Crack CFFA-6 -20° F
Hydrolysis 7 Weeks
Flammability**
CAL TB 117-2013 Passes
NFPA 260 Class 1
UFAC Class 1
ASTM E-84 Class A or 1
BIFMA CS-191-53, Sec. 3 Passes
BIFMA Upholstery, Sec. 4 Passes
IMO 2010 FTP Part 8, 3.1 Passes
Recommended Cleaning
Please refer to Detailed Cleaning Instructions.
Although we try hard to make sure colors on our site are accurate, actual colors may vary. Please order samples prior to making a purchase.
The use of polyurethane for welt cord in upholstery applications is strongly discouraged. Even though Burch's polyurethane products are designed to exceed industry abrasion standards, when used with welt cord the exposed material becomes more vulnerable to abrasion and may experience premature de-lamination. Burch cannot be held responsible for damage that may occur when used in a welt cord application.
Final determination of the suitability of this product for an application rests with the user.
* Abrasion test results exceeding ACT Performance Guidelines are not an indicator of product lifespan. Multiple factors affect fabric durability and appearance retention.
** This term and any corresponding data refer to the typical performance in the specific tests indicated and should not be construed to imply the behavior of this or any other material under actual fire conditions.
